Vortex Razor HD 4000 Laser Rangefinder

The Vortex Razor HD 4000 Laser Rangefinder is built for the extreme hunter, archer, and shooter. Angle compensated, this rangefinder features four targeting modes; Normal, First, Last, and extended for any ranging environment. The primary Horizontal Component Distance mode provides the angle compensated range information needed by the majority of shooters in a simple easy to read display. This range finder also features a Line Of Sight mode and scan feature.

Optical Features:

• • • HD Optical System Optimized with select glass elements to deliver exceptional resolution, cut chromatic aberration and provide outstanding color fidelity, edge-to-edge sharpness and light transmission.
    • XR Plus Fully Multi-Coated Ultimate anti-reflective coatings on all air-to-glass surfaces provide maximum light transmission for peak clarity and the pinnacle of low-light performance.

Construction Features:

• • • ArmorTek Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt.
    • Waterproof O-ring seals prevent moisture, dust and debris from penetrating for reliable performance in all environments.
    • Rugged Design Built to handle tough situations. Compact and lightweight.
    • Rubber Armor Provides a secure, non-slip grip, and durable external protection.
    • Diopter Adjusts for differences in a user's eyes. Located on right eyepiece.
    • Tripod Adaptable Compatible with a tripod adapter, allowing use on a tripod or car window mount.
    • Magnesium Chassis Decreases weight and increases strength.

Performance Features:

• • • ELR Ideal for ranging targets at extreme distances. A slightly longer response time allows greatly extended range distances. Best used on a tripod.
    • HCD Horizontal Component Distance (HCD) mode for angle compensated ranging.
    • LOS Line of Sight (LOS) mode displays actual line of sight range.
    • Scan This feature displays continual distance readings when panning across a landscape or tracking a moving animal.
    • Easy-to-use Menu Intuitive, easy-to-use menus feature a simple, clean illuminated display.
    • AWC All Weather Capable ranging allows the unit to return a distance even in a variety of adverse weather conditions.
    • Ranging Format Range in yards or meters.

HCD Corrected Shoot-To Range:

• • • The Razor HD 4000 uses HCD (Horizontal Component Distance) angle-compensated ranging technology to give bow and rifle shooters the critical distance data needed to make accurate shots.

DEER RANGE:

• • • NORMAL MODE: 1,600 yds (1,463 m)
    • NORMAL MODE (SCAN): 2,000 yds (1,829 m)
    • ELR MODE: 2,200 yds (2,012 m)

TREE RANGE:

• • • NORMAL MODE: 1,800 yds (1,646 m)
    • NORMAL MODE (SCAN): 2,200 yds (2,012 m)
    • ELR MODE: 2,500 yds (2,286 m)

REFLECTIVE RANGE:

• • • NORMAL MODE: 2,400 yds (2,194 m)
    • NORMAL MODE (SCAN): 2,400 yds (2,194 m)
    • ELR MODE: 4,000 yds (3,658 m)

Included in the Box:

• • • Carrying case
    • Lens cloth
    • Hex wrench
    • CR2 battery

Features:

• • • Range Reflective (yards): 4000
    • Range Tree (yards): 2500
    • Range Deer (yards): 2200
    • Accuracy (< 199.9 yds): .5 yds
    • Accuracy (200 - 1000 yds): 1 yds
    • Accuracy (> 1000 yds): 2 yds
    • Max Angle Reading: + / - 70 degrees
    • Magnification: 7x
    • Objective Lens Diameter: 25 mm
    • Linear Field of View: 341.25 ft @ 1,000 yds
    • Angular Field of View: 6.5 degrees
    • Eye Relief: 16-19 mm
    • Length: 4.49 inches
    • Width: 1.34 inches
    • Weight: 9.9 oz
